Survey meter 6150 AD 5 and 6

Detector

Energy-compensated GM (Geiger Müller) counter (H*(10))

Dose equivalent rate display ranges

• AD 5: from 0.1 μSv/h to 1,000 mSv/h
• AD 6: from 0.01 μSv/h to 10 mSv/h

Dose equivalent display ranges

• AD 5: from 1 μSv to 10 Sv
• AD 6: 1 μSv to 100 mSv

Energy ranges

• AD 5: 45 keV to 3 MeV
• AD 6: 60 keV to 1.3 MeV

Display

Digital and trend bar graph on LCD screen

Operating temperature range

From -30°C to +50°C

Communication

RS232

Power supply

Standard 9 V battery

Operating time

1000 hours

Housing

Cast aluminum

Protection

IP 67 (waterproof under 1 m of water)

Dimensions

130 x 80 x 29 mm

Weight

400 g

Quick and easy monitoring

The AD 6150 features a dual display, counting scale, and digital display.
With its 4-button interface, it’s easy to use.

Robust

With its compact aluminium case, it is particularly well suited to professional use in nuclear or industrial environments, as well as for first-aid teams. It is also waterproof and decontaminable.

Versatile

As a multi-probe device, the AD 6150 can be used for a wide range of measurements:
• very low or high gamma dose rate,
• remote gamma measurements
• alpha/beta surface contamination control

Transport

Case, strap and carrying case

Bracket

Wall bracket, alarm station, multiplexer

Communication

RS485 adapter

External probes

• Telescopic probe 6150 AD t
• Low-flow sensor 6150 AD 18
• High-flow sensor 6150 AD 15
• Very high flux probe 6150 ADb
• Alpha, beta, gamma surface probe 6150 AD 17
• Alpha, beta, gamma surface probe 6150 ADk

Other option

Explosion-proof version available for monitor 6150 AD5 EX and low-flow probe 6150 AD18 EX
